Full package installation, including Intellian v100NX

Full package installation, including Intellian v100NX

Installation of full package hardware kit, including Intellian v100NX (VSAT) for fishing vessel at Canary Islands, Spain.

Huge fishing vessel was interested in high speed Internet connectivity - they have about 150 crew members onboard while they sail near West Africa. Also, vessel asked us to provide our high quality HD VoIP service for business purposes and for private usage by crew mwmbers.

To choose correct channel bandwidth Customer first made a choice on 4/1 Mbps (MIR) and 512/256 Kbps (CIR) package, but later decided to improve experience and switched to profile of 8/2 Mbps (MIR) and 2/0,5 Mbps (CIR) package. Such a switch was made completely remotely by personnel of Teleport.

The task with Internet access for crew members via vouchers was solved by using Hotspot and RADIUS software and a web interface to manage all the activities. Responsible persons got administrator accounts to manage the system locally, also we made a remote connectivity to manage the system from Customer's office.

The HD VoIP-telephony system required some development from our side. In a process of development of this solution we used existing open-source technologies and software and made a redesign of our previous system. Also we made a research on how to reach best voice-over-IP quality on limited channels with high delay and jitter. So, by combining the blocks we achieved perfect results - call bandwidth including overhead uses only 30/30 Kbps per 1 call and correct choice of codec provided required HD voice quality for both speaking parties.

Ubiquity Unifi Rack

Also during the project we made a core of internal LAN using Ubiquity Unifi network hardware - USG Router, Unifi Switches, Unifi AP AC LR wifi access points and even CloudKey controller.
